Brush Plates

Fulfilled by

Brush Plates are ideal supporting, guiding and transporting, pressing or cleaning delicate items without damage. Available in custom made sizes and shapes up to 2500 mm x 1200 mm

This product isn't available to purchase online. Please send us your enquiry and we will get back to you.

Enquire now
KOTI-Dawson Brush Plates
KOTI-Dawson Brush Plate supporting a pressed steel panel
KOTI-Dawson profiled Brush Plate
KOTI-Dawson Brush Plate with sculptured edges

Description

Custom made to your requirement, our Brush Plates are ideal for supporting, guiding or transporting, cleaning or pressing delicate items without damage and minimising noise. With a low frictional resistance and carrying capacity of up to 2000 kg per m2, tufted Brush Plates are constructed on a synthetic or fibreboard core in any shape or size up to 1200 mm x 2500 mm.

Depending on your application, we can vary the brush height, stiffness, tuft pattern and density using a selection of synthetic or heat resistant fill materials.

Features

  • Perfect for transporting heavy and delicate items
  • Unlimited shape and size up to 1200 mm x 2500 mm
Core material: Polypropylene, PVC, Polyethylene
Fill material: Synthetic, abrasive, wire, natural or mixed materials
Fill colour: Colours available on request
Tuft angle Upright or angled
Tuft density Open, dense or very dense
Tuft method: Machine stapled
Tuft pattern In line or staggered
Trim profile Straight

Help me choose

To help you choose your ideal Brush Plate solution, we need to know a few details. It also helps if you can tell us a little about your application. Please refer to our available dimensions and materials, but if you’re not quite sure what you need or would like some advice, simply get in touch and we’ll see how we can help.

How to configure your Brush Plate

  • Brush type: BP
  • Brush length (BL):
  • Brush height (BH) or Total height (TH):
  • Brush width (BW):
  • Fill material:
  • Core length (KL):
  • Core width (KW):
  • Core thickness (KT):
  • Core material:
  • Additional features:

If you would like to see which materials best suit your application, take a look at our quick guide to fill materials.

Dimensions and materials

Brush Plate

Koti tufted-brush--brush-plate-01-drawing
KOTI-Dawson custom shape Brush Plate layout



Koti tufted-brush--brush-plate-02-drawing
KOTI-Dawson rectangular Brush Plate layout
Dimensions Fill material
Type Core
length		 Core
width		 Core
thickness		 Brush
length		 Brush
height		 Synthetic Wire
KL (max) KW (max) KT (Max) BL (max) BH (max) Ø (max) Ø (max)
BP 2500 1200 30 2490 150 0.90 0.50

All dimensions in mm
